I am currently in the process of designing a triple layered fabric. One layer shall carry conductive warp threads (one out of every three), another layer shall carry conductive weft threads (again, one out of every three) and a third layer shall lay between them and act as an insulator, keeping them apart and preventing unwanted contact between the two conductive layers. Constructing a treble cloth is a compicated process. The way that a treble cloth is woven is that first the face cloth is woven, then the centre cloth is woven, then the back cloth is woven. This is a draft for a treble cloth. The crosses indicate weaving marks for the cloth currently being woven, the dashes are lifts and are used to indicate shafts that are being lifted in the case of layers that are above the layer currently being woven. Blue is back, Red is front, Green is centre (All three layers are plain weave btw) The cloth is constructed like so 1: Back cloth is woven. All red and green marks are lif
Comments
Thanks for commenting on my blog - it led me to your textile odyssey at Galashiels. Weave on!
Any extraneous buttons and hems and so on that aren't got rid of by this method I just cut off. I like to keep things fairly regular.
